- Size: 18
- Place of Origin: Shandong
- Brand Name: Shandong Longxing Chemical Machinery Group Co. Ltd
- Model Number: DSH
- Weight: 2520.000 kg
Features:
This machine have heater type, vacuum type and heavy type. And it can be equipped with a jacket.
When the raw material has high viscosity, we can use screwed ribbon to mix.
The inlet hole is like a wintersweet. And according to customers’ demand we can design it as disk of valve, ball valve, YCD-HX etc. .
The drive form has manual form and pneumatic form.
- Size: 18
- Place of Origin: Shandong
- Brand Name: Shandong Longxing Chemical Machinery Group Co. Ltd
- Model Number: DSH
- Weight: 2520.000 kg
Type | DSH-0.3c DSH-0.3p | DSH-0.5 DSH-0.5p | DSH-1c DSH-1p | DSH-1.5c DSH-1.5p | DSH-2c DSH-2p | DSH-3c DSH-3p | DSH-4c DSH-4p | DSH-6c DSH-6p | DSH-8c DSH-8p | DSH-10c DSH-10p | DSH-12c | |||||||||||||
Full Volume (m 3) | 0.3 | 0.5 | 1 | 1.5 | 2 | 3 | 4 | 6 | 8 | 10 | 12 | |||||||||||||
Load Factor | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | |||||||||||||
Output (t/h) | 0.3-1 | 0.5-1.5 | 2-2.5 | 2-4 | 2.5-5 | 3.5-8 | 5-10 | 7.5-15 | 10-12 | 12-25 | 15-30 | |||||||||||||
Total Power(kw) | A | 3.55 | 3.55 | 4.55 | 4.75 | 6.05 | 8.05 | 12.5 | 16.5 | 20 | 20 | 23.5 | ||||||||||||
B | 2.2 | 3 | 4 | 5.5 | 5.5 | 7.5 | 11 | 15 | 18.5 | 18.5 | 22 | |||||||||||||
Particle Size (mesh) | 20-450 | |||||||||||||||||||||||
Mixing uniformity | Relative deviation < 1.5% | |||||||||||||||||||||||
Revolution | 2 | |||||||||||||||||||||||
Rotation | A | 143 | 57 | 70 | ||||||||||||||||||||
B | 143 | 57 | ||||||||||||||||||||||
Miximum Diameter(mm) | 930 | 1130 | 1500 | 1633 | 1830 | 2040 | 2250 | 2548 | 2780 | 3018 | 3204 | |||||||||||||
Weight(kg) | 550 | 600 | 1200 | 1350 | 1500 | 2300 | 2520 | 3160 | 3600 | 3950 | 4150 | |||||||||||||
